BDS Suspension 6.5" High Clearance Lift Kit 20-25 GM 2500HD / 3500

Product image 1
Product image 2

BDS Suspension 6.5" High Clearance Lift Kit 20-25 GM 2500HD / 3500

BDS Suspension 6.5" High Clearance Lift Kit 20-25 GM 2500HD / 3500

Bring your L5P Duramax powered Chevrolet or GMC to new heights (literally) with this monster 6.5" High Clearance System from the suspension gurus at BDS. At the heart of this new 6.5" systems BDS utilizes a pair of 1/4" thick laser cut high clearance crossmembers to maximize clearance and provide a solid mounting point for the OE lower control arms. These paired with the heavy duty front skid plate create a rigid subframe while adding protection for vital steering and driveline components. In place of the factory steering knuckles are a pair of specially designed ductile iron replacement steering knuckles are supplied to maintain proper steering geometry for ESC system compatibility. The front differential is repositioned with BDS's multipoint relocation bracket system to secure the front differential to keep CV axle angles at a minimum. To help maximaze clearance a pair of torsion bar relocations brackets are supplied to mount to the lower control arms to retain the factory high clearance frame mounted crossmember. A pair of BDS-branded sway bar drop brackets used to correct the operating angle of the factory sway bar along with extended length braided stainless steel brake lines. Rounding out the front of this kit are FOX 2.0 performance series IFP shocks.

In the rear of this 6.5" lift system 5" lift blocks and longer u-bolts to lift and level the stance. Also included, BDS supplies brake line and ABS line relocation brackets allow the use of factory brake lines. Lastly a matching set of FOX 2.0 performance series IFP shocks are supplied to compliment the front setup. All kits come finished in a durable textured black powdercoat and sent with all hardware packs to complete the install along with step-by-step installation instructions. All BDS kits include Factory Protection Plus for the ultimate extended warranty to include BDS's No Fine Print Warranty, ESC system compatibility and a 5year-100mile drivetrain warranty to match the dealer. Improve the look and capability of your Chevy/GMC 2500/3500HD truck with this new 6.5" lift system from BDS Suspension.

Shock Options:

  • NX2 Nitro Series Shocks - BDS NX2 series gas shocks offer impressive performance on and offroad. They use a nitrogen-charged, twin-tube design with 10-stage velocity-sensitive valving for lightning-fast dampening and superior control.
  • FOX 2.0 Performance Series Shocks - Fox 2.0 performance series shocks have been tuned and tested by both FOX and BDS Suspension to maximize performance specific to each application and every BDS Suspension system. The Internal Floating Piston (IFP) shock design is based on proven Fox Racing Shocks race products but re-designed to maximize the ride quality, handling, and control of your BDS-equipped truck, whether on or off the road.

Single Steering Stabilizer Mounting Kit

Are you worried about your steering control? NX2 Nitro Steering Stabilizer is designed to be a high-end performance shock at an affordable price. Built with a durable metallic finish, a large fluon-banded piston, and self-lubricating seals this stabilizer is tough enough to last but tuned with vehicle-specific valving to give you amazing control. Built with both the morning commute and some light off-roading in mind, keep stress out of your steer and install one of these today!

Recoil Traction Bar Kit

Increase your traction and stability without limiting your movement with this BDS Recoil Traction Bar Kit. When your truck is in high torque situations, you need extra help absorbing shocks or vibrations through your system. Install these traction bars to smooth out your ride, increase stability while off-roading, and increase durability throughout your truck.

Carrier Bearing Drop Kit

A 2-piece rear drive shaft will require some extra work as the geometry of your drive system will now have some added stress. We recommend adding this carrier bearing drop to avoid any potential driveline vibration with the added lift height.

Select Does Your Truck Have Rear Overload Springs?
Select Select Shocks
From $751.66

Original: $2,505.53

-70%
BDS Suspension 6.5" High Clearance Lift Kit 20-25 GM 2500HD / 3500—

$2,505.53

$751.66

Product Information

Shipping & Returns

Description

Bring your L5P Duramax powered Chevrolet or GMC to new heights (literally) with this monster 6.5" High Clearance System from the suspension gurus at BDS. At the heart of this new 6.5" systems BDS utilizes a pair of 1/4" thick laser cut high clearance crossmembers to maximize clearance and provide a solid mounting point for the OE lower control arms. These paired with the heavy duty front skid plate create a rigid subframe while adding protection for vital steering and driveline components. In place of the factory steering knuckles are a pair of specially designed ductile iron replacement steering knuckles are supplied to maintain proper steering geometry for ESC system compatibility. The front differential is repositioned with BDS's multipoint relocation bracket system to secure the front differential to keep CV axle angles at a minimum. To help maximaze clearance a pair of torsion bar relocations brackets are supplied to mount to the lower control arms to retain the factory high clearance frame mounted crossmember. A pair of BDS-branded sway bar drop brackets used to correct the operating angle of the factory sway bar along with extended length braided stainless steel brake lines. Rounding out the front of this kit are FOX 2.0 performance series IFP shocks.

In the rear of this 6.5" lift system 5" lift blocks and longer u-bolts to lift and level the stance. Also included, BDS supplies brake line and ABS line relocation brackets allow the use of factory brake lines. Lastly a matching set of FOX 2.0 performance series IFP shocks are supplied to compliment the front setup. All kits come finished in a durable textured black powdercoat and sent with all hardware packs to complete the install along with step-by-step installation instructions. All BDS kits include Factory Protection Plus for the ultimate extended warranty to include BDS's No Fine Print Warranty, ESC system compatibility and a 5year-100mile drivetrain warranty to match the dealer. Improve the look and capability of your Chevy/GMC 2500/3500HD truck with this new 6.5" lift system from BDS Suspension.

Shock Options:

  • NX2 Nitro Series Shocks - BDS NX2 series gas shocks offer impressive performance on and offroad. They use a nitrogen-charged, twin-tube design with 10-stage velocity-sensitive valving for lightning-fast dampening and superior control.
  • FOX 2.0 Performance Series Shocks - Fox 2.0 performance series shocks have been tuned and tested by both FOX and BDS Suspension to maximize performance specific to each application and every BDS Suspension system. The Internal Floating Piston (IFP) shock design is based on proven Fox Racing Shocks race products but re-designed to maximize the ride quality, handling, and control of your BDS-equipped truck, whether on or off the road.

Single Steering Stabilizer Mounting Kit

Are you worried about your steering control? NX2 Nitro Steering Stabilizer is designed to be a high-end performance shock at an affordable price. Built with a durable metallic finish, a large fluon-banded piston, and self-lubricating seals this stabilizer is tough enough to last but tuned with vehicle-specific valving to give you amazing control. Built with both the morning commute and some light off-roading in mind, keep stress out of your steer and install one of these today!

Recoil Traction Bar Kit

Increase your traction and stability without limiting your movement with this BDS Recoil Traction Bar Kit. When your truck is in high torque situations, you need extra help absorbing shocks or vibrations through your system. Install these traction bars to smooth out your ride, increase stability while off-roading, and increase durability throughout your truck.

Carrier Bearing Drop Kit

A 2-piece rear drive shaft will require some extra work as the geometry of your drive system will now have some added stress. We recommend adding this carrier bearing drop to avoid any potential driveline vibration with the added lift height.
